Océ VarioPrint 6330/6270/6220/6180 TITAN

  • 商品介紹
  • 產品規格

Océ VarioPrint 6330/6270/6220/6180 TITAN

業界最快的、最好的量產型黑白印刷機

體驗市場上最快的印刷速度，以及無出其右的可靠性和影像品質 – Océ VarioPrint 6000 TITAN 系列。VarioPrint 6000 TITAN 系列適用於多達每月 1,000 萬次的大量列印，結合媲美平版印刷的黑白列印與低功耗、最低噪音和臭氧排放*。它是您印刷事業的一大助力。

  • 利用可現場升級的速度授權應對業務的季節性高峰
  • 領先業界的黑白印刷速度，每分鐘高達328面
  • 獨特的 Gemini 雙子星技術可同時列印正反面，實現近乎完美的對位
  • 列印薄紙至 45 磅(選配)或最大 350 x 500mm 的紙張，提供 4 頁合一書本列印
  • 低功耗、最低噪音和臭氧排放
  • 適用於多達每月 1,000 萬次的大量列印


產品特色

領先市場的生產力

VarioPrint 6000 TITAN 系列是最快的單張數位黑白量產型印刷機，可讓使用者以前所未有的速度交付工作並配合緊湊的時程。此系列的 A4 速度高達 328 ipm，輸出比競爭機
型快 5 - 9%，在市場上獨領風騷。進一步提高生產力的 VarioPrint 6000 TITAN 系列採用以快速嵌入式 APPE 為基礎的 PRISMAsync列印伺服器，在 IPDS 與 PDF 工作流程之間順暢切換。

既可靠又便利

列印速度不是 VarioPrint 6000 TITAN 系列的唯一特色。此生產印刷機擁有堅固的金屬設計、可靠的免停止翻面紙張路徑和穩定的列印流程，可靠性和正常運作時間遠遠勝過市場競爭對手。由於紙張輸入和輸出容量龐大，VarioPrint 6000 TITAN系列能無人化運作長達四小時，並可透過PRISMAsync伺服器提前八小時設定排程。此外，還能利用PRISMAsync 遠端控制應用程式隨時掌握狀況：取得傳送至智慧型手機的預防性通知和緊急通知。

近乎完美的對位

Gemini 雙子星技術是一種創新的即時雙面列印技術，可同時列印正反頁面，排除對位不準確性，且不必停止和翻面，提供近乎完美的輸出。VarioPrint 6000 TITAN 系列產
生銳利且媲美平版印刷的輸出，採用多項獨特技術：CopyPress可輕鬆處理高紋理性紙張，低溫處理則可確保列印後紙張保持平整。ScreenPoint可根據列印內容將每頁最佳化，SuperCell的智慧半色調演算法則以 180每英吋線數 (lpi) 造就銳利的重現效果，並以237 灰階呈現細膩的影像和平順的漸變。

您的隨需印製工廠

Océ VarioPrint 6000 TITAN已經是黑白書冊印刷的業界標準，藉由 Gemini 雙子星技術近乎完美的對位和高達 350x500mm 的大格式列印 – 實現真正的 4 頁合一書本格式列
印。您也可以有效率地處理小量列印，讓您透過完整的點對點工作流程進入新市場，例如一次性書本列印和個人化書本。VarioPrint
6000 TITAN 可協助您提供啞光平版印刷的列印品質、完美的平整輸出，甚至使用重量低達 45 磅(選配) 的紙張。

最高永續性認證

VarioPrint 6000 TITAN系列體現永續黑白列印，確保乾淨、產生幾乎為零的臭氧排放量、低放熱和低噪音輸出 – 造就舒適的工作環境。

型錄下載
GENERAL SPECIFICATIONS
Imaging technology Océ Gemini Instant Duplex technology
Speed Océ VarioPrint 6330*
  • 328 A4 prints per minute
  • 171 A3 prints per minute

Océ VarioPrint 6270
  • 272 A4 prints per minute
  • 146 A3 prints per minute

Océ VarioPrint 6220
  • 221 A4 prints per minute
  • 118 A3 prints per minute

Océ VarioPrint 6180
  • 182 A4 prints per minute
  • 97 A3 prints per minute

Note: Print speed can also be influenced by the paper quality setting
Maximum Monthly Print Volume (A4) Océ VarioPrint 6330*
1,000,000 – 10,000,000

Océ VarioPrint 6270
750,000 – 8,000,000

Océ VarioPrint 6220
500,000 – 5,000,000

Océ VarioPrint 6180
300,000 – 2,500,000
PRINTING
Job management DocBox, Queue and History, Waiting Room
Print resolution 600x600 dpi or 600x1200 dpi, 180lpi
Registration tolerance Maximum < 0.3 mm
Maximum printable area Long edge: maximum 486 mm
Short edge: maximum 318 mm
CONTROLLER
Processor 2.9 GHz
Memory 8 GB DDR 1333MHz
Hard disk 2x 500 GB
Operating Panel Intuitive 15" high resolution touch screen user interface
Network connectivity 10/100/1000 MB, 2x 1GB Ethernet network ports
Network protocols TCP/IP (LPR/LPD, socket), SMB static/auto IP (via DHCP) SNMP v1-v3 (printer MIB, private MIB, Job monitoring MIB), IPP
Operating system Microsoft®Windows 10®
Supported Page Description Languages (PDL) APPE (Adobe® PDF Print Engine)
  • Adobe® PostScript® 3TM / streaming PostScript®
  • PPML/GA Level 1
  • PPML versions 1.5,2.1 and 2.2
PDF 1.7
PCL 6
Xerox® PPP support
IPDS(options)
Print from USB PDF, PS, PCL, XPS via USB connection on operator panel
Security Common Criteria EAL 2+, E-shredding, HTTPs, Firewall, PIN for Doc Box, User authentication to SDS, IPv6, software protection license (integrity checker), user authentication per user role: key operator, system administrator and service representative
Features Print while RIP, Streaming, Multi-job processing, Pre-RIP, no cycle-down between jobs, web-based configuration with Settings Editor, Remote meter reading, Remote Diagnostics, Remote software upgrade, Remote Monitor, Remote Manager
Controller hardware optionals Generic USB mouse support
CCD interface; Copy Control Device interface for pre-paid accounting Included: Operator attention light; giving visual status signals of the printer
SOFTWARE INTEROPERABILITY
Océ PRISMAaccess, Océ PRISMAprepare, Océ PRISMAspool, Océ PRISMAproduction, Océ PRISMAdirect, Océ VPconvert V7, PRISMAaudit, GMC PrintNet, InfoPrintManager AIX, Xerox FreeFlow Makeready v7 (and higher), EFI Fiery Central 1.8.2, Kodak Smartboard V5
PAPER HANDLING
Paper Input Standard


Options		 Paper module with 4 paper trays
(2 x 1700 sheets + 2 x 600 sheets)

Second and third paper module
Maximum paper capacity 24,000 A4 sheets from 4 standard and 8 optional paper trays (80 gsm media)
Dual paper tray option to increase A4 paper input capacity
Paper weight 45 - 50 gsm with the optional light-weight media module
50 - 300 gsm for Canon recommended media
60 - 200 gsm for other media
Coated media 120 - 200 gsm: standard,
80 - 120 / 200 - 250 gsm: only for approved media
Paper size 203 x 203 mm - 350 x 500 mm;
Statement (178 x 254 mm)**
PAPER INPUT MODULE STANDARD
Description Standard paper input module which is minimally required to make a configuration. With double sheet detection, air separation with vacuum feed and pre-separation technologies.
Paper Trays 2 x 600 sheets, 2 x 1,700 sheets (80 gsm)
Standard paper capacity 4,600 sheets
Paper size 203 x 203 mm - 488 x 320 mm;
Statement (178 x 254 mm)**
Dimensions (WxDxH) 940 x 716 x 1150 mm
Weight 180 kg
PAPER INPUT MODULE OPTIONAL
Description Next to the standard paper module, two extra paper modules can be included. With air separation with vacuum feed and pre-separation technologies.
Paper Trays 2 x 600 sheets, 2 x 1700 sheets (80 gsm) per paper module
Maximum paper capacity 16,000 sheets (sum of 2 paper modules with dual paper tray)
Paper size 203 x 203 mm - 488 x 320 mm;
Statement (178 x 254 mm)**
Dimensions (WxDxH) 940 x 716 x 1150 mm
Weight 180 kg
PAPER INPUT MODULE FLEX
Description Flexible paper input module that can also handle 350x500 paper sizes. Can be used as Standard Paper module (as first module after the engine). With double sheet detection, air separation with vacuum feed and pre-separation technologies.
Paper Trays 2 x 600 sheets, 2 x 1650 sheets (80 gsm) per paper module
Paper size Upper 2 trays: 203 x 203 mm (LEF) - 488 x 320 mm;
Statement (178 x 254 mm)
2 bulk trays: 203x208 mm (LEF) - 500 x 350 mm (SEF)
Max paper size 350 x 500 mm in flex-xl trays only (bulk trays)
Min paper size Normal trays: same as Standard Paper module; flex-xl trays 203 x 208 mm
Dimensions (WxDxH) 940 x 716 x 1150 mm
Weight 180 kg
HIGH CAPACITY STACKER
Description Three high capacity stackers can be included
Stacks Paper size 2 x 3,000 sheets (80 gsm) per stacker.
All paper input sizes and weights are supported
Maximum paper capacity 18,000 sheets (3 stackers)
Dimensions (WxDxH) 1150 x 736 x 1150 mm
1150 x 736 x 1928 mm(including set finisher)
Weight 160 kg (290 kg including set finisher)
Features Tab printing, DFD finishing for third-party finishing
SET FINISHER OPTIONAL
Description Optional Staple and stacker finisher in combination with High Capacity Stacker
Output capacity 4,000 sheets (80 gsm, A4)
Stapling capacity 100 sheets (80 gsm)
Paper size 208 x 275 mm - 220 x 306 mm
Stapling Corner stapling, Two-side stapling
Stapling positions Portrait, Landscape, Book
Features Optional 50 sheet staple cartridge and staples (Specially suited for thin documents)
PRINT GUARD
Description Post fuser entity for VarioPrint 6000 MICR TITAN series and optional for VarioPrint 6000 TP TITAN
Dimensions (WxDxH) 750 x 850 x 1200 mm
Weight 178kg
LIGHT WEIGHT MEDIA KIT
Description Special installation kit for the engine to support the use of media >44 gsm, requires pressurized air, recommended in case of light weight media specialization
Paper size VP6000 standard sizes are supported.
Max media size will be 350 x 500 with Flex-XL PIM
Paper Weight >44 gsm plain paper, grain direction in transport direction
ENVIRONMENTAL
Ozone emissions Ozone emission in running condition (mg/m2): <= 1mg/hr
Sound power level Noise in standby condition: <69 dB(A)
Noise in printing condition: < 84 dB(A)
Power consumption
  • Standby 0,9 KW
  • Sleep mode engine: 32W
  • Sleep mode controller: 44W
  • Off mode: 6w
  • Running:
    VP6180 : 4,0 kW
    VP6220 : 4,3 kW
    VP6270 : 4,4 kW
    VP6330 : 4,9 kW

Print mode controller: 67W
(at 80 g/m2- 20 lb bond paper weight)
Product Safety & Environment RoHS compliance, Cetecom / CE Class A, FCC Class A, UL / TüV / CE, VCCI, China RoHS, CB Report
Other compliances Section 508, De-ink ability certificate, C-tick Australia (sourced locally by NSO/RSHQ)
DIMENSIONS AND WEIGHTS
DIMENSIONS AND WEIGHTS
Items Weight(Kg) Length(mm) Width(mm) Height(mm)
Print Engine (PE) 779 1439 1070 1225
Paper Input Module (PIM1) 180 940 716 1150
Input Interface Module (IIM) 100 470 720 1150
High Capacity Stacker including finisher (HCS/FIN) 290 1150 736 1928
High Capacity Stacker (HCS) 160 1150 736 1169
Paper Input Module Flex 180 940 716 1150

* not available as MICR version
** with optional statement size support insert
Canon recommends you use Canon Media for the best results.
Please check media (paper) compatibility list to see which variety of paper/media is recommended.
Some images are simulated for clarity of reproduction.
All data is based on Canon’s standard testing methods.
Final specifications are subject to change without notice.
™ and ®: All company and/or product names are trademarks and/or registered trademarks of their respective manufacturers in their markets and/or countries
